Ex Series Ex450
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8170-27100 KNOB, MAIN SHIFT 1
2 CY-198133-27350 BOOT 1
3 CY-1A7780-27800 SHIFT ASSY, COLUMN 1
4 CY-198075-18311 PIN 8X52 1
5 CY-198133-27060 SPRING,REVERSER 1
6 CY-198133-27070 SPRING 1
7 CY-1A7780-27360 LEVER,MAIN SHIFT 1
8 CY-198133-27401 SHAFT,MAIN CHANGE 1
9 CY-198133-27652 BRACKET,COLUMN SHIFT 1
10 CY-198133-27711 STAY,MAIN CHANGE 1
11 CY-198133-27720 BUSHING 2
12 CY-1A7780-27750 LEVER,REVERSER 1
13 CY-198133-27781 HOLDER,REVERSER 1
14 CY-198133-27820 SPRING,REVERSR.RETRN 1
15 CY-198133-27850 JOINT MAIN CHG 1
16 CY-198133-27881 FLANGE UNIT,REVERSER 1
17 CY-198133-27940 SHAFT,REVERSER COMP. 1
18 CY-22137-140000 WASHER 14,POLISHED 1
19 CY-22137-220000 WASHER 22 1
20 CY-22217-080000 WASHER, 8 1
21 CY-22272-000190 CIRCLIP E-19 2
22 CY-22351-020012 SPRING PIN 2X 12 1
23 CY-22351-060032 SPRING PIN 6X32 1
24 CY-22351-080040 SPRING PIN 8X40 1
25 CY-22417-200300 COTTER PIN 2.0X30 1
26 CY-26106-060162 BOLT M 6X 16 PLATED 3
27 CY-26106-060162 BOLT M 6X 16 PLATED 2
28 CY-26116-080252 BOLT M 8X 25 PLATED 1
29 CY-198133-27950 STAY,CLM.SHIFT COMP. 1
30 CY-22217-080000 WASHER, 8 1
31 CY-26106-080162 BOLT M 8X 16 PLATED 2
32 CY-26106-080162 BOLT M 8X 16 PLATED 2
33 CY-26106-100202 BOLT M10X 20 PLATED 2
34 CY-26116-080252 BOLT M 8X 25 PLATED 1
95
FIG. 46. MAIN CHANGE LEVER
Copyright 2008 Cub Cadet Yanmar LLC
