DES-3010F/DES-3010FL/DES-3010G/DES-3018/DES-3026 Fast Ethernet Switch Manual
MAC Address
Figure 11- 15. MAC Address Table
The following fields can be viewed or set:
Parameter Description
VLAN Name
Enter a VLAN Name by which to browse the forwarding table.
MAC Address
Enter a MAC address by which to browse the forwarding table.
Port
Select the port by using the corresponding pull-down menu.
Find
Allows the user to move to a sector of the database corresponding to a user defined port,
VLAN, or MAC address.
VID
The VLAN ID of the VLAN of which the port is a member.
MAC Address
The MAC address entered into the address table.
Port
The port to which the MAC address above corresponds.
Type
Describes the method which the Switch discovered the MAC address. The possible entries
are Dynamic, Self, and Static.
Next
Click this button to view the next page of the address table.
View All Entry
Clicking this button will allow the user to view all entries of the address table.
This allows the Switch's dynamic MAC address
forwarding table to be viewed. When the
Switch learns an association between a MAC
address and a port number, it makes an entr
into its forwarding ta
le. These entries are the
used to forward packets through the Switch.
To view the MAC Address forwarding table,
from the Monitoring menu, click the MAC
Address link:
150
