Parameter Description
From and To
Ports being configured for 802.1x settings.
Capability
Two role choices can be selected:
Authenticator - A user must pass the authentication process to gain access to the network.
None - The port will not be controlled by the 802.1x functions.
Guest VLANs
Figure 10- 16. Guest VLAN Authentication Process
On 802.1X security enabled networks, there is a need for no
n
802.1X supported devices to gain limited access to the network,
due to lack of the proper 802.1X software or incompatible
devices, such as computers running Windows 98 or lowe
r
operating systems, or the need for guests to gain access to the
network without full authorization or local authentication on the
Switch. To supplement these circumstances, this switch no
w
implements Guest 802.1X VLANs. These VLANs should have
limited access rights and features separate from other VLANs o
n
the network.
To implement Guest 802.1X VLANs, the user must first create a
VLAN on the network with limited rights and then enable it as a
n
802.1X guest VLAN. Then the administrator must configure the
guest accounts accessing the Switch to be placed in a Gues
t
VLAN when trying to access the Switch. Upon initial entry to the
Switch, the client wishing services on the Switch will need to be
authenticated by a remote RADIUS Server or local authenticatio
n
on the Switch to be placed in a fully operational VLAN. I
f
authenticated and the authenticator posseses the VLAN
p
lacement information, that client will be accepted into the full
y
operational target VLAN and normal switch functions will be
open to the client. If the authenticator does not have target VLAN
p
lacement information, the client will be returned to its
originating VLAN. Yet, if the client is denied authentication b
y
the authenticator, it will be placed in the Guest VLAN where i
t
has limited ri
g
hts and access. The ad
j
acent fi
g
ure should
g
ive the
Limitations Using the Guest VLAN
1. Ports supporting Guest VLANs cannot be GVRP enabled and vice versa.
2. A port cannot be a member of a Guest VLAN and a static VLAN simultaneously.
3. Once a client has been accepted into the target VLAN, it can no longer access the Guest VLAN.
4. If a port is a member of multiple VLANs, it cannot become a member of the Guest VLAN.
