DES-3010F/DES-3010FL/DES-3010G/DES-3018/DES-3026 Fast Ethernet Switch Manual
ID
A unique identifier for the session, in the form of a printable ASCII string of at least three
characters.
Authentic Method
The authentication method used to establish the session. Valid Authentic Methods include:
(1) Remote Authentic Server - The Authentication Server is external to the Authenticator’s
System.
(2) Local Authentic Server - The Authentication Server is located within the Authenticator’s
System.
Authenticator Statistics
This table contains the statistics objects for the Authenticator PAE associated with each port. An entry appears in this table for
each port that supports the Authenticator function. To view the Authenticator Statistics, click Monitoring > Port Access Control
> Authenticator Statistics.
Figure 11- 26. Authenticator Statistics window
The user may select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. The
default value is one second.
The following fields can be viewed:
Parameter Description
Port
The identification number assigned to the Port by the System in which the Port resides.
Frames Rx
The number of valid EAPOL frames that have been received by this Authenticator.
Frames Tx
The number of EAPOL frames that have been transmitted by this Authenticator.
Rx Start
The number of EAPOL Start frames that have been received by this Authenticator.
TxReqId
The number of EAP Req/Id frames that have been transmitted by this Authenticator.
RxLogOff
The number of EAPOL Logoff frames that have been received by this Authenticator.
Tx Req
The number of EAP Request frames (other than Rq/Id frames) that have been transmitted by
161
