Dual-Speed Stackable Hub Web-based Management User’s Guide
Web-based Network Management86
♦ Group Role
The role of the Hub within the stack, either pri-
mary-master, backup-master, or slave.
♦ Hardware Revision
The version of the repeater hardware board used
in this Hub.
♦ Status
Tells whether the Hub is
up
(online and working) or
down
.
♦ Last Operation Status Change
Time of the last status change for the
Hub. A status change occurs when the Hub goes online or offline.
♦ Isolated/ Reconnected Group
This is an option to isolate or reconnect
the Hub to the hub stack.
Out-of-Band/ Console Configuration
Clicking on the word
Console
which will appear on the representation of the
hub stack if a console is present, allows the Hub diagnostic port to be con-
figured. The diagnostic port can be set to
Console
(in-band) for VT-100
and terminal emulation which may be necessary for basic configurations and
initial setup, or to
out-of-band
management which enables the hub to be
managed using SNMP via the diagnostic port.
