DGS-3130 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
370
Figure 9-92 Host Key (Generating) Window
After the key was successfully generated, the following window will appear.
Figure 9-803 Host Key (Generating, Success) Window
SSH Server Connection
This window is used to view the SSH server connections table.
To view the following window, click Security > SSH > SSH Server Connection, as shown below:
Figure 9-814 SSH Server Connection Window
SSH User Settings
This window is used to display and configure the SSH user settings.
To view the following window, click Security > SSH > SSH User Settings, as shown below:
Figure 9-825 SSH User Settings Window
The fields that can be configured are described below:
Parameter Description
User Name
Enter the SSH user’s username used here. This name can be up to 32
characters long.
