Parameter Description
traffic will not be processed. Ignoring the received remote loopback feature will
prevent the port from entering the remote loopback mode.
Remote Loopback Select the remote loopback action here. Options to choose from are Start and
Stop.
• Start - Specifies to request the peer to change to the remote loopback
mode.
• Stop - Specifies to request the peer to change to the normal operation
mode.
If the remote peer is configured to ignore the remote loopback request, then the
remote peer will not enter or exit the remote loopback mode upon receiving the
request. To start the remote peer to enter the remote loopback mode,
administrators must ensure that the local client is in the active mode and the
OAM connection is established. If the local client is already in the remote
loopback mode, then this feature cannot be applied.
Click the Apply button to accept the changes made.
The fields that can be configured in Ethernet OAM Table are described below:
Parameter Description
Unit Select the Switch unit ID that will be used here.
From Port - To Port Select the Switch port range that will be used here.
Click the Find button to locate a specific entry based on the information entered.
Click the Show All button to display all the entries.
Ethernet OAM Configuration Settings
This window is used to display and configure the Ethernet OAM configuration settings.
To view the following window, click OAM > Ethernet OAM > Ethernet OAM Configuration Settings, as shown
below:
