DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
197
Authenticator Session Statistics
This window contains the session statistics objects for the Authenticator PAE associated with each port. An entry appears in this
table for each port that supports the Authenticator function.
To view the Authenticator Session Statistics window, click Monitoring > Port Access Control > Authenticator Session
Statistics.
Figure 11- 18. Authenticator Session Statistics window
The user may select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. The
default value is one second.
The following fields can be viewed:
Parameter Description
Port
The identification number assigned to the Port by the System in which the Port resides.
Octets Rx
The number of octets received in user data frames on this port during the session.
Octets Tx
The number of octets transmitted in user data frames on this port during the session.
Frames Rx
The number of user data frames received on this port during the session.
