DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
80
802.1Q VLAN Batch Settings
The function allows the user to create an 802.1Q VLAN Batch.
To view this window click L2 Features > 802.1Q VLAN Batch Settings.
Figure 7- 8. 802.1Q VLAN Batch Settings window
The following fields can be set:
Parameter Description
VID List
This field is used to specify the VID range. Supported VIDs on the Switch range from ID
number 1 to 4094. Use the drop-down menu to specify whether to Add, Delete or Config a
specific VID List.
Advertisement
Enabling this function will allow the Switch to send out GVRP packets to outside sources,
notifying that they may join the existing VLAN.
Port List
Specifies the port or range of ports to be configured.
