D-Link DIR-895L

172D-Link DIR-895L User Manual
Section 6 - Quick VPN
Quick VPN Server Setup Instructions
Congure the following options:
Click Save and proceed to client setup pages.
DIR-895L HW:A1 FW:1.12
Features >> Quick VPN
Quick VPN
Quickly and easily create a prole for secure remote access to a Local Area Network (LAN). This prole can
be used to congure other devices to connect to your LAN via a secure VPN tunnel.
Settings FeaturesHome Management
Save
L2TP over IPsec:
Enabled
Username:
VPN_Username
Password:
A_Str0nG_P@ssW0rd!%!
PSK:
A_Str0nG_P@ssK3y!%!
Save Conguration To Local Hard Drive:
Save
General
Username: MSCHAPv2
⌵
MPPE: RC4-128
⌵
Advanced
Advanced Settings ...
COPYRIGHT © 2016 D-Link
L2TP over IPSec: Enable or disable the Quick VPN server.
If you enable Quick VPN, the following options are available:
Username: . Enter a username between 1 and 15 characters
Password: Enter a password between 1 and 15 characters.
PSK: Enter a passkey between 6 and 64 characters.
Save
Conguration To
Local Hard Drive:
For Apple iOS devices and OS X: From a computer browser click
this button to export a prole to simplify setup. E-mail this le as an
attachment to your Apple mobile device or open the le in OS X.
Authentication
Protocol:
Choose the authentication protocol type: MSCHAPv2, PAP, or CHAP.
MSCHAPv2 is the default.
MPPE: Select the encryption cipher strength: none, RC4-40, or RC4-128.
RC4-128 is the default.
Click Save when you are done.
