D-Link DIR-895L

84D-Link DIR-895L User Manual
Section 4 - Conguration - Router Mode
Turn IPv4 Filtering OFF
⌵
Turn IPv4 Filtering OFF
Turn IPv4 Filtering ON and ALLOW rules listed
Turn IPv4 Filtering ON and DENY rules listed
DIR-895L HW:A1 FW:1.12
Features >> Firewall Settings >> IPv4
Settings FeaturesHome Management
Save
IPv6 RulesAdvanced
Firewall Settings
Your router’s high-performance rewall feature continuously monitors Internet trafc, protecting your network
and connected devices from malicious Internet attacks.
Name Schedule Edit Delete
Remaining: 24
Add Rule
COPYRIGHT © 2016 D-Link
IPv4/IPv6 Rules
The IPv4/IPv6 Rules page contains advanced options that let you set rules to restrict IP trac
across your network or from your network to the Internet. To congure IPv4 rules, click IPv4
Rules from the Firewall Settings page. To congure IPv6 rules, click IPv6 Rules from the
Firewall Settings page. To return to the main Firewall Settings page, click Advanced.
Use the drop-down menu to select whether you want to ALLOW or DENY the rules you
create. You can also choose to turn ltering OFF.
If you wish to remove a rule, click on the corresponding trash can icon in the Delete column.
If you wish to edit a rule, click on the corresponding pencil icon in the Edit column. If you
wish to create a new rule, click the Add Rules button. Click Save when you are done. If you
edit or create a rule, the following options will appear:
Create New Rule
Name: Enter a name for the rule.
Source IP Address
Range:
Enter the source IP address range that the rule will apply to, and using
the drop-down menu, specify whether it is a WAN or LAN IP address.
Destination IP
Address Range:
Enter the destination IP address range that the rule will apply to, and
using the drop-down menu, specify whether it is a WAN or LAN IP
address.
Port Range: Select the protocol of the trac to allow or deny (Any, TCP, or UDP)
and then enter the range of ports that the rule will apply to.
Schedule: Use the drop-down menu to select a schedule to apply. The schedule
may be set to Always Enable, or you can create your own schedules
in the Schedules section. Refer to Schedule on page 94 for more
information.
Click Save when you are done.
Name:
Source IP address Range:
WAN
⌵
Destination IP Address Range:
WAN
⌵
Port Range:
TCP
⌵
Schedule:
Always Enable
⌵
Create New Rule
Apply
