D-Link DIR-895L

16D-Link DIR-895L User Manual
Section 3 - Installation - Router
4. Use the included Ethernet cable to connect your modem to the yellow port labeled INTERNET on the router.
5. Turn on or plug your modem back in and wait approximately one minute before proceeding onward.
DIR-895L
DIR-895L
DIR-895L
Modem
Modem
Note: This unit is to be used with power supply model DA-60N12.
6. Connect the supplied power adapter to the router and a power outlet, press the power button, and verify that the power LED is lit. Allow 1
minute for the router to boot up.
Modem
Hardware Setup (continued)
