VLAN Bridging
The VLAN bridging feature allows advanced users to enable 802.1Q VLAN tagging on the
WAN interface. If you have an Ultra Fast Broadband (UFB) ber optic connection, your ISP
may oer High Priority Committed Information Rate (CIR). This guarantees the bandwidth
required for real time voice and video applications.
In order to utilize the CIR, your must know the proper 802.1Q VLAN tags that your ISP uses.
To enable this functionality, dene the VLAN IDs, apply the VLAN to the desired interface,
and connect your devices. Additional 802.1p tag conguration options will be available via
future rmware update.
VLAN Bridge
Internet VLan ID: Enter the VLan ID for Internet trac.
IPTV VLAN ID: Enter the VLAN ID for IPTV trac.
VoIP VLAN ID: Enter the VLAN ID for VoIP trac.
WAN Connection: Select the VLAN to apply to the corresponding interface.
Internet VLan ID: 621 (2~4094)
IPTV VLan ID:
823 (2~4094)
VoIP VLan ID:
400 (2~4094)
Interface WAN Connection
LAN Port1
Internet
⌵
Internet
IPTV
VoIP
LAN Port2
Internet
⌵
LAN Port3 Internet
⌵
LAN Port4 Internet
⌵
Wireless Internet
⌵
Wireless Guest Zone Internet
⌵
VLAN Bridge
