D-Link DSL-G2452DG User Manual

20D-Link DSL-G2452DG User Manual
Section 4 - Configuration
Click the IPv4 button to see the IPv4 information for each WAN interface. Click the green
arrows to select different interfaces.
WAN Interface: Displays the currently selected interface: Ethernet, DSL, or USB.
Cable Status: Displays the current cable connection status.
Connection Type: Displays the network protocol used to obtain an IP address.
Network Status: Displays the current network connection status.
Connection
Uptime:
Displays the amount of time the connection has been connected.
MAC Address: The WAN interface's MAC address is listed here.
IP Address: The WAN IP address is listed here.
Default Gateway: The default gateway IP address is listed here.
Primary DNS
Server:
Displays the current primary DNS server.
Secondary DNS
Server:
Displays the current secondary DNS server.
IPv4
