DVG-2102S User’s Manual ADVANCED
D-Link Systems, Inc. 47
3-2-1-8 Fax
ADVANCED → VoIP → FAX
FAX / Modem: Select the mode to detect if there is a fax tone and transfer the call to a fax line.
Note: When a fax tone is detected from the call, the VoIP Telephone Adapter will automatically switch from
voice mode to fax mode. Hence, the fax settings will be temporarily applied to a specific port which detects
the fax tones, instead of its default voice settings.
Function Fax Detection Content of SDP of re-INVITE re-INVITE with T.38
Disable No N/A Accept and change RTP to T.38
T.38 Fax Yes re-INVITE with T.38 and T.30 Accept and change RTP to T.38
T.30 Fax Yes re-INVITE with T.30 Accept and change RTP to T.38
T.30
Fax/Modem
Detect CED
only
re-INVITE with T.30 Accept and change RTP to T.38
T.30 Only No N/A Accept and change RTP to T.38
T.38 Native Yes re-INVITE with T.38 Accept and change RTP to T.38
