7D-Link DAP-2680 User Manual
Hardware Overview
Connections
4
No. Item Description
2 LAN (PoE) Port
Connect to a Power over Ethernet (PoE) switch or router
via an Ethernet cable.
3 Power Receptor Connect the power adapter.
4 Reset Button
Press and hold for ten seconds to reset the access point to the
factory default settings. Press and hold for one second to reboot
the access point.
LED
No. Item LED Color Description
1
Power/Status
LED
Solid Red
Indicates the access point has
malfunctioned.
Solid Green
Indicates that the DAP-2680 is
working properly.
Hardware Overview
