1-11
GENERAL INFORMATION
ITEM SPECIFICATIONS
CLUTCH TYPE Multiplate Wet Clutch / 5
TRANSMISSION TYPE Constant Mesh
GEAR RATIO 1st 3.200(37/12 T)
DRIVE TRAIN
GEAR RATIO 2nd 2.143(32/17 T)
GEAR RATIO 3rd 1.438(29/21 T)
GEAR RATIO 4th 1.095(23/21 T)
GEAR RATIO 5th 0.923(24/26 T)
GEARSHIFT PATTERN Left foot operated return system
Down 1-N-2-3-4-5 Up
IGNITION TYPE Full Transisterized
IGNITION TIMING “F” MARK 18°BTDC / 1,600(rpm)
FULL ADVANCE 30°BTDC / 8,500(rpm)
AC GENERATOR 12V-17A/5,000(rpm)
BATTERY CAPACITY 12V 10AH
SPARK PLUG CR9EH-9
SPARK PLUG GAP 0.8 -0.9mm
FUSE CAPACITY 30A
STARTING SYSTEM Starter Motor
ELECTRICAL
HEADLIGHT (HIGH/LOW BEAM) 55W/55W
POSITION LAMP 5W
TURN SIGNAL LAMP 10W×4
STOP/TAIL LIGHTS 21W/5W
SPEEDOMETER LAMP 3W
NEUTRAL INDICATOR LAMP LED×1
HIGH BEAM INDICATOR LAMP LED
WINKER INDICATOR LAMP LED
LICENCE PLATE LAMP 5W
TACHOMETER LAMP LED×1
MALFUNCTION INDICATOR LAMP LED
