DAELIM VJF125 - Coolant Level Inspection; Coolant Replacement

2-15
INSPECTIONS / ADJUSTMENTS
• Fill the radiator with new coolant.
COOLANT CAPACITY : 1,100
±±
20cc
RADIATOR CAPACITY : 1,000
±±
20cc
RESERVE TANK CAPACITY: 280
±±
20cc
• Start the engine. Bleed air from the coolant and
check the level of coolant.
• Install the radiator cap.
• Fill the coolant with the reserve tank up to the
upper level.
• Erect the main stand prior to beginning work.
• Check the coolant level and the reserve tank.
• The level should be between the “UPPER” and
“LOWER” level lines.
• Fill the coolant to the reserve tank up to the “F”
(upper level).
• Remove the radiator cap.
• Remove the drain bolt and drain the coolant. (Tilt
the vehicle to the right in order to assure complete
and rapid draining.)
• Install the drain bolt.
COOLANT LEVEL INSPECTION
COOLANT REPLACEMENT
•Unless the coolant is refilled or replaced, the
engine temperature too high or low.
•Fill to the “F”(UPPER LEVEL) line.
