14-1
14. FRONT WHEEL/FRONT FORK/STEERING
SERVICE INFORMATION
GENERAL SAFETY
A contaminated brake disk and pad reduce stopping power. Discard contaminated pads and clean a contaminated disk
with a brake degreasing agent.
Because inhaled asbestos fibers have been found to cause respiratory disease and cancer, work so that the fibers near
the brake pad can't spread to the brake cleaner.
When removing or installing tires from the rim, use the special tire lever and rim protector so that the rim can't be
damaged.
This section covers maintenance of the front wheel, front fork and steering stem. Refer to section 15 for front brake
service.
Use a jack or a hoist under the engine to support the motorcycle.
SPECIFICATIONS
TORQUE VALUES
STEERING HANDLE PIPE BOLT 2.6kgf m(26N m)
FRONT BRAKE DISK BOLT 4.2kgf
m(42N m)
FRONT AXLE NUT 5.9kgf
m(59N m)
FORK TOP BRIDGE PINCH BOLT 2.6kgf
m(26N m)
FORK BOTTOM BRIDGE PINCH BOLT 3.4kgf
m(34N m)
FORK TUBE CAP BOLT 2.3kgf
m(23N m)
FORK SOCKET BOLT 2.0kgf
m(20N m) (Apply locking agent)
CALIPER BRACKET BOLT 3.0kgf
m(30N m)
STEERING STEM NUT 7.4kgf
m(74N m)
STEERING TOP THREAD NUT 2.5kgf
m(25N m) (Initial torque)
0.3kgf
m(3N m) (Last torque)
HANDLE WEIGHT SOCKET BOLT 2.0kgf
m(20N m)
SERVICE INFORMATION
········
14-1
TROUBLESHOOTING
··········
14-2
HANDLEBARS
··············
14-3
FRONT WHEEL
············
14-7
FRONT FORK
··············
14-12
STEERING STEM
············
14-20
FRONT AXLE DEFLELTION - 0.2
FRONT WHEEL RIM VIBRATION
- 2.0
- 2.0
FRONT FORK PIPE DEFLECTION - 0.2
FRONT FORK FLUID CAPACITY 245
±
2.5cc -
FORK SPRING FREE LENGTH 528.0 480.0
RADICAL
AXIAL
ITEM STANDARD VALUE SERVICE LIMIT
Unit : mm
