HEADLIGHT

BULB REPLACEMENT

Remove the headlight dust cover.

Install in the reverse order of removal

Push the headlight retainer and remove the bulb.

HEADLIGHT CASE REMOVAL/INSTALLATION

Remove

- Center cowl

- Side cowl RH/CH

- Front cowl stay

- Inner panal

Remove the headlight case mounting bolts and

headlight case from the headlight stay.

Disconnect the all cords from the wiring.

Remove the headlight case.

Install in the reverse order of removal.

Loosen the flange bolt secured front cowl stay.

Remove the headlight, winker, speedometer coupler.

If you touch the bulb with your bare hands, clean it

with a cloth moistened with denatured alcohol to

prevent early bulb failure.

Avoid touching Halogen headlight bulb. Finger

prints can create hot sport that cause a bulb to

break.

20-2

LIGHTS/SWITCHES/HORN

FLANGE BOLT

HEAD LIGHT DUST COVER

FLANGE BOLT

FLANGE BOLT HEADLIGHT CASE

HEADLIGHT CASE
