EMS(Engine Management System)
5-42
Remove
Loosen the 2 special screws.
Remove the tank cover.
Remove the fuel tube.
Remove the fuel pump coupler.
Loosen the 4 special screws and remove the
fuel pump setting plate.
Remove the fuel pump.
It is located inside a fuel tank
Remove the seat.
Loosen the washer bolt, 2 flange bolts
securing fuel tank.
Loosen the 4 socket bolts and remove the fuel
filler cap.
The key is off before disassembly.
18.FUEL PUMP
!
CAUTION
△
To Next Page
