DAELIM VJF125 - INSPECTIONS;ADJUSTMENTS

2-1
2. INSPECTIONS/ADJUSTMENTS
SERVICE INFORMATION
•The exhaust gas contains poisonous substance. Do not keep engine idling in a closed or poorly ventilated place for a
long period of time.
SPECIFICATIONS
TIRES
2
SERVICE INFORMATION
······
2-1
MAINTENANCE SCHEDULE
···
2-3
FUEL LINE (FUEL TUBE)
······
2-4
THROTTLE GRIP OPERATION
····
2-4
AIR CLEANER
·· ·· ·· ·· ·· ·· ··
2-5
SPARK PLUG
·· ·· ·· ·· ·· ·· ··
2-5
VALVE CLEARANCE
·· ·· ·· ··
2-6
CYLINDER COMPRESSION PRESSURE
··
2-7
DRIVE CHAIN
················
2-8
DRIVE CHAIN SLIDER
·· ·· ·· ··
2-9
BRAKE FLUID
········ ······
2-9
BRAKE PAD WEAR
·· ·· ·· ·· ··
2-9
BRAKE SYSTEM
·· ·· ·· ·· ·· ··
2-10
BRAKE STOP SWITCH
········
2-11
HEADLIGHT AIM
·· ·· ·· ·· ·· ··
2-11
CLUTCH SYSTEM
············
2-11
SIDE STAND
·· ·· ·· ·· ·· ·· ·· ··
2-12
SUSPENSION
·· ·· ·· ·· ·· ·· ··
2-13
BOLTS, NUTS, FASTENERS
······
2-13
WHEEL/TIRE
················
2-14
STEERING STEM
·········· ··
2-14
COOLANT LEVEL INSPECTION
····
2-15
COOLANT REPLACEMENT
····
2-15
THROTTLE GRIP PLAY 2~6mm
SPARK PLUG CR9EH-9
SPARK PLUG GAP 0.8~0.9mm
IN. 0.15mm
EX. 0.20mm
CARBURETOR IDLE SPEED 1,600rpm
±100rpm
CYLINDER COMPRESSION 13.0kgf/㎠ ( 600rpm )
DRIVE CHAIN SLACK 10~20mm
REAR BRAKE PEDAL FREE PLAY 10~20mm
CLUTCH LEVER FREE PLAY 10~20mm
•For information on engine oil and oil filter, refer to sections 3-3 and 3-4.
•Stand the main stand prior to beginning work.
VALVE CLEARANCE
COLD TIRE
PRESSURE
TIRE SIZE
DRIVER ONLY
DRIVER AND A
PASSENGER
FRONT
REAR
FRONT
REAR
FRONT
REAR
FRONT
REAR
2.00kgf/㎠ (200kPa, 29psi )
2.00kgf/㎠ (200kPa, 29psi )
2.00kgf/㎠ (200kPa, 29psi )
2.25kgf/㎠ (225kPa, 32psi )
110/70-17 54S
140/60-17 69S
5.5mm
7.0mm
TIRE PART MINIMUM-DEPTH
