19-1
19. ELECTRIC STARTER
SERVICE INFORMATION
GENERAL SAFETY
·Always turn the ignition switch OFF before servicing the starter motor. The moter could suddenly start, causing
serious injury.
The starter motor can be maintained without removing the engine from the vehicle.
A weak battery may be unable to turn the starter motor quickly enough, or supply adequate ignition current.
If the current is kept flowing through the starter motor to turn it while the engine is not cranking over, the starter motor
may be damaged.
SPECIFICATION
TOOLS
MULTI TESTER
VERNIER CALIPER
SCANNER
19
STARTING DIAGRAM
········
19-0
SERVICE INFORMATION
········
19-1
TROUBLESHOOTING
··········
19-2
STARTER MOTOR
············
19-3
STARTER MAGNETIC SWITCH
··
19-6
ITEM
STARTER MOTOR BRUSH LENGTH
STANDARD VALUE
10.2mm
SERVICE LIMIT
5.0mm
Unit : mm
