DAELIM VJF125 - Rear Wheel;Rear Suspension

15-1
15.
REAR WHEEL/REAR SUSPENSION
SERVICE INFORMATION
SPECIFICATIONS
TORQUE VALUES
REAR BRAKE DISK BLOT 4.2㎏f·m
REAR AXLE NUT 8.8㎏f·m
REAR CUSHION UPPER / DOWN BOLT 5.4㎏f·m
REAR CUSHION UNDER BOLT 4.0㎏f·m
SWINGARM PIVOT NUT 8.8㎏f·m
FINAL DRIVEN SPROCKET NUT 5.9㎏f·m
TOOLS
ATTACHMENT
PILOT
DRIVER
BEARING REMOVER SHAFT
BEARING REMOVER HEAD
15
SERVICE INFORMATION
····
15-1
TROUBLESHOOTING
·····
15-2
REAR WHEEL
········
15-3
REAR CUSHION
······
15-7
SWINGARM
·········
15-9
ITEM STANDARD VALUE SERVICE LIMIT
AXLE RUNOUT - 0.2
REAR WHEEL RIM RUNOUT
- 2.0
- 2.0
REAR CUSHION SPRING FREE LENGTH 131 -
RADICAL
AXIAL
Unit : mm
