TORQUE
1-13
GENERAL INFORMATION
REFERENCE
THREAD DIA
(mm)
Q’TY
ITEM
*Torque specifications listed above are for important fastener. Other should be tighten to the standard torque values below.
*SH(Small Head) : It describe 6mm bolt of 8mm flange bolt.
TYPE
TORQUE
TYPE
TORQUE
kgf
·
mN
·
m kgf
·
mN
·
m
15mm BOLT, NUT 4.0~6.0 0.45~0.6 5mm SCREW 3.4~5.0 0.35~0.5
16mm BOLT, NUT 8~12 0.8~1.2
6mm SCREW, FLANGE BOLT
7~11 0.7~1.1
18mm BOLT, NUT 18~25 1.8~2.5
6mm FLANGE BOLT, NUT
9.8~14 1.0~1.4
10mm BOLT, NUT 29~39 3.0~4.0
8mm FLANGE BOLT, NUT
24~29 2.4~3.0
12mm BOLT, NUT 49~59 5.0~6.0
10mm FLANGE BOLT, NUT
34~44 3.5~4.5
(Include SH type)
kgf.m,(N,m)
FRAME
2
2
1
6
4
4
2
1
1
2
2
2
1
2
2
4
2
5
M8×1.25
M6×1.0
M14×1.5
M8×1.25
M10×1.25
M8×1.25
M6×1.0
M22×1.0
M22×1.0
M8×1.25
M8×1.25
M8×1.25
M14×1.25
M10×1.25
6mm Tapping
M8×1.25
M8×1.25
M8×1.25
U- NUT
U- NUT
2.8~3.4
1.0~1.4
5.5~6.5
4.0~4.5
3.0~4.0
2.8~3.4
1.0~1.4
6.0~9.0
0.25~0.35
2.4~3.0
3.0~4.0
2.4~3.0
8.0~10.0
3.5~4.5
0.5~0.7
4.0~4.5
1.8~2.5
4.0~4.5
REAR CALIPER BRACKET BOLT
REAR MASTER CYLINDER HOLDER SOCKET BOLT
FRONT AXLE NUT
FRONT BRAKE DISK BOLT
BRAKE OIL BOLT (FRONT/REAR)
CALIPER BRACKET BOLT (FRONT/REAR)
FRONT MASTER CYLINDER HOLDER BOLT
STEERING STEM NUT
STEERING TOP THREAD
FORK TOP BRIDGE PINCH BOLT
BOTTOM BRIDGE PINCH BOLT
FORK HANDLE PIPE MOUNTING BOLT
SWINGARM PIVOT NUT
REAR CUSHION UPPER/UNDER BOLT
CHAIN SLIDER SCREW
L. DOWNTUBE COMP ‘B’
HANDLE WEIGHT SOCKET BOLT
REAR BRAKE DISK SOCKET BOLT
