DAELIM VJF125 - Steering Stem

14-20
FRONT WHEEL/FRONT FORK/STEERING
STEERING STEM
REMOVAL
Remove the following :
- Front wheel
- Kandle bars
- Front fork
Remove the 2 flange bolts and front brake hose stay.
Remove the steering stem nut.
Remove the steering head top thread nut using the
special tool.
TOOL : STEERING STEM SOCKET
Remove the following :
- Steering top cone race
- Steering steel ball
- Steering stem
Check the steel ball, cone race, ball race for damage or
abnormal wear and replace as necessary.
Place a shop towel under the steering stem to
catch the steel balls.
