15-5
REAR WHEEL/REAR SUSPENSION
Turn the each bearing.
Replace it if damaged.
REPLACEMENT BEARING
Install the bearing remover into the bearing.
install the bearing remover shaft at the opposite
position, and remove the wheel bearing by heating
with a hammer.
After removing the distance collar, remove the other
bearing.
TOOLS :
BEARING REMOVER SHAFT
REMOVER HEAD
Apply the grease to the bearing.
Insert the new bearing in parallel with the seal side
facing outside. After inserting the distance collar, insert
the bearing of the right side with the seal facing
outside.
TOOLS :
DRIVER
ATTACHMENT
PILOT
•If the wheel bearing was replaced, Be sure to
replace it with new one.
ASSEMBLY
