DAELIM VJF125 - Page 44

3-5
LUBRICATION
INSPECTION
• Install the inner and outer rotors into the oil pump
body.
• Measure the pump body clearance.
SERVICE LIMIT : 0.25mm
ASSEMBLY
• Clean all parts with fresh cleaning oil.
• Install the lnner and outer rotor to the pump body.
INSTALLATION
• Install the oil filter cover to the RH.crank case.
•Fill the recommended oil into the crankcase. (⇨3-3)
• Measure the rotor end clearance.
SERVICE LIMIT : 0.20mm
•After installing, check the oil pump to operate
smoothly
• Clean the oil pump body (inner and outer) and rotors
with fresh cleaning oil.
