12.ETS(ENGINE TEMPERATURE SENSOR)
Remove
After pressing the ETS coupler and pull it..
Remove the ETS.
Remove the ETS coupler.
Assemble
Install in reverse order of removal.
It is located on the left-hand side of cylinder
head.
The key is off, before disassembly.
!
