DAELIM VJF125 - O2(Oxygen) Sensor

EMS(Engine Management System)
5-33
Remove
Center cowl
O2 sensor coupler
Check the O2 sensor.
It is located on the exhaust pipe
The key is off before disassembly.
Handle with care or fraglile.
14.O2(Oxygen) SENSOR
!
CAUTION
△
Assemble
Install in reverse order of removal.
