CE ENGINE FUEL SYSTEM
5-28
©
200416
Removal and installation
2
ΧΦ65/75/85 series
4
Low-pressure fuel pipes fitted with VOSS
quick-release couplings
Removing low-pressure fuel pipes
1. Disconnect the fuel pipe (2) by inserting the
special tool (1)(DAF no. 1329470) into the
quick-release coupling and removing the
pipe from the coupling.
2. Remove the special tool from the quick-
release coupling.
3. Plug the openings.
Fitting low-pressure fuel pipes
1. Clean the quick-release coupling parts and
apply a thin layer of clean engine oil to the O-
ring.
2. Fit the pipe on the quick-release coupling of
the component and push the pipe onto it until
a clear resistance can be felt and the quick-
release coupling audibly clicks.
3. Bleed the fuel system. See "Inspection and
adjustment".
4. Start the engine and check the fuel system
for leaks.
i400473
1
2
