200324 2-1

General

XE ENGINE INLET/EXHAUST SYSTEM

CF65/75/85 series

2. GENERAL

2.1 LOCATION OF COMPONENTS

1. Air intake pipe

2. Wastegate diaphragm

3. Turbocharger

4. Exhaust elbow with integrated butterfly valve

5. Exhaust brake valve

I400531
