DAF CF75 Series Service Manual

CE ENGINE INLET/EXHAUST SYSTEM
3-2
©
200416
Inspection and adjustment
3
ΧΦ65/75/85 series
4
3.2 INSPECTING TURBOCHARGER AXIAL BEARING PLAY
Note:
The turbocharger axial bearing play should only
be checked when the engine is cold.
1. Remove the exhaust pipe from the
turbocharger.
2. Remove the charge pipes from the
turbocharger.
3. Fit a dial gauge (1) to the charge supply
flange of the turbocharger.
4. Push the compressor shaft away from the
dial gauge and set the gauge to zero.
5. Push the compressor shaft to the dial gauge
and read off the axial play. Compare the
reading with the specified value; see
"Technical data". Replace the turbocharger if
necessary.
6. Fit the charge pipes to the turbocharger.
7. Fit the exhaust pipe to the turbocharger.
i400821
1
