200324 4-3
Removal and installation
PE ENGINE INLET/EXHAUST SYSTEM
CF65/75/85 series
4
6
4.2 REMOVAL AND INSTALLATION OF AIR COOLER
Note:
The removal and installation procedure of the air
cooler allows for the presence of an air-
conditioning unit.
If such a unit is not present, the sections
concerned can be skipped. Draining and filling of
the air-conditioning system must only take place
if the workshop is certified to do this.
Removing the air cooler
1. Disconnect the earth lead from the battery
terminal.
2. Drain the engine coolant from the radiator.
3. Disconnect the pipe from the bottom of the
radiator.
4. Carefully disconnect the air-conditioning
compressor and condenser and hang them
to one side (the system must not be opened).
5. Disconnect the oil filler pipe and hang it to
one side.
6. Disconnect all coolant hoses (A, B and C)
connected to the radiator.
M201031
E
A
C
A
B
D
