DAF CF75 Series Service Manual

©
200416 4-5
Removal and installation
CE ENGINE INLET/EXHAUST SYSTEM
ΧΦ65/75/85 series
4
3
Installing the air cooler
1. Fit the air cooler and secure it against the
radiator.
2. Fit the air-conditioning condenser (if
applicable) including accessories onto the
radiator.
3. Fit the air-conditioning compressor, if
applicable, to the engine.
4. Install the torque rods (D).
5. Fit all rubber hoses that run along the air
cooler.
6. Fit the air inlet hoses (C) between the engine
and the air cooler.
7. Fit the dipstick holder (B) to the air cooler.
8. Fit the oil filler pipe (A) to the air cooler.
9. Top up the cooling system.
i400871
C
D
A
C
B
D
