CE ENGINE FUEL SYSTEM
4-4
©
200416
Inspection and adjustment
2
ΧΦ65/75/85
series
4
Fleetgua
rd fuel p
refilter/water separato
r
1.
Unscr
ew the button
of the primer pu
mp and
pull it ou
t.
2.
Use the pr
imer pump
until a clear
ly higher
resistanc
e is per
ceptible
.
3.
Hand-t
ighten the bu
tton.
i4 00 712
