XE ENGINE FUEL SYSTEM
4-12
©
200324
Removal and installation
8
CF65/75/85 series
4
Installing the pump housing
1. Fit two new lubricating oil connection sealing
rings.
2. Fit the pump housing using the lifting gear
(DAF no. 1329499). Tighten the attachment
bolts to the specified torque. See "Technical
data".
3. Fit the camshaft position sensor.
4. Fit the fuel temperature sensor connector.
5. Fit the electrical connections onto the pump
units.
6. Fit the injection pipes.
7. Connect the fuel pipes of the fuel lift pump.
8. Fit the pressure relief valve onto the pump
housing.
9. Fit the fuel pipes to the pump housing.
10. Fit a dry new timing case seal (6) using the
special tool (DAF no. 1329318).
11. Check whether cylinder 1 is at top dead
centre (TDC on the flywheel, cylinder 6 in
overlap position).
46
7
M200841
