Local Configurations 101
Parameter
Description
each channel window in the live view screen.
In the Channel Title box, enter the name for the selected channel.
Table 5-26
Click Apply to complete the settings. Step 3
Click Copy to copy the settings to other channels.
5.5.5 Configuring Covered Area Settings
Select Main Menu > CAMERA > OVERLAY > Cover-Area. Step 1
The Cover-Area interface is displayed. See Figure 5-67.
Figure 5-67
Configure the settings for the covered area parameters. See Table 5-27. Step 2
Parameter
Description
Channel
In the Channel list, select the channel that you want to configure the
settings for.
Preview
Preview: Select the Preview check box to apply the configured

covered block to the selected channel window in the live view
screen.
Record: Select the Record check box to apply the configured

