Local Configurations 103
The 1724 channels are only for IP camera and the range changes dependent on
the model you purchased.
The channel selection for analog camera or IP camera are in sequence, for
example, if you want to select channels for IP camera, you need to select from the
last channel number Channel 16 first, which means, you cannot jump to select the
channel 15 directly until you have selected the channel 16.
Click Apply and follow the onscreen instructions to complete the settings. Step 3
5.5.7 Upgrading Coaxial Camera
Select Main Menu > CAMERA > COAXIAL UPGRADE. Step 1
The COAXIAL UPGRADE interface is displayed. See Figure 5-69.
Figure 5-69
Click Browse. Step 2
The Browse interface is displayed.
Select the upgrade file and then click OK. Step 3
The COAXIAL UPGRADE interface is displayed.
You need to insert the USB storage device that contains the upgrading files.
Select the check box of the channel that you want to upgrade. Step 4
Click Start Upgrade. Step 5
If the upgrading is successful, the system pops up a message indicating the upgrading
is completed.
