The Grand Tour 15
No.
Port Name
Function
1
Status indicator light
Glows blue when the device is working properly.
2
HDD
Glows blue when HDD status is abnormal.
3
NET
Glows blue when network status is abnormal.
4
POWER
Glows blue when the power is connected properly.
5
USB port
Connects to peripheral devices such as USB storage
device, keyboard, and mouse.
Table 3-9
3.1.10 DH-XVR5832S-X
Figure 3-10
No.
Port Name
Function
1
Status indicator light
Glows blue when the device is working properly.
2
HDD
Glows blue when HDD status is abnormal.
3
NET
Glows blue when network status is abnormal.
4
POWER
Glows blue when the power is connected properly.
5
USB port
Connects to peripheral devices such as USB storage
device, keyboard, and mouse.
Table 3-10
