Compatible Backup Devices 306

Manufacturer

Series

Model

Capacity

Port Mode

HITACHI

Ultrastar series (SAS

interface)

HUS726060AL5210

6TB

SATA

Seagate

Pipeline HD Mini

ST320VT000

320GB

SATA

Seagate

Pipeline HD Mini

ST500VT000

500GB

SATA

Seagate

Pipeline HD Mini

ST2000LM003 (EOL)

2TB

SATA

TOSHIBA

2.5-inch PC series

MQ01ABD050V

500GB

SATA

TOSHIBA

2.5-inch PC series

MQ01ABD100V

1TB

SATA

SAMSUNG

HN-M101MBB

HN-M101MBB (EOL)

1TB

SATA

Seagate

2.5-inch enterprise

series

ST1000NX0313

1TB

SATA

Seagate

2.5-inch enterprise

series

ST2000NX0253

2TB

SATA

Cybersecurity Recommendations2
Regulatory Information4
Foreword5
Important Safeguards and Warnings8
Table of Contents9
Introduction14
Overview14
Functions14
Getting Started16
Checking the Components16
Installing HDD16
Dh-Xvr5108C-X/Dh-Xvr5104C-4Kl-X/Dh-Xvr5104C-X17
Dh-Xvr4104C-X/Dh-Xvr4108C-X17
Dh-Xvr7108E-4Kl-B-X18
Vr5104Hs-X/ Dh-Xvr4104Hs-X/Dh-Xvr5104H-X/Dh-Xvr5104He-X/Dh-Xvr4108Hs-X19
Dh-Xvr5216An-4Kl-X-16P20
Dh-Xvr7416L-4Kl-X/Dh-Xvr5432L-X20
Dh-Xvr7816S-4Kl-X/Dh-Xvr5832S-X21
Installing Device into Rack21
The Grand Tour23
Front Panel23
Dh-Xvr5108C-X/Dh-Xvr5104C-4Kl-X/Dh-Xvr5104C-X23
Dh-Xvr4104C-X/Dh-Xvr4108C-X23
Dh-Xvr7108E-4Kl-B-X24
8Hs-X/Dh-Xvr5116Hs-X/Dh-Xvr5104Hs-4Kl-X/Dh-Xvr5108Hs-4Kl-X/ Dh-Xvr5104Hs-X/Dh-Xvr4104Hs-X/Dh-Xvr4108Hs-X/Dh-Xvr5104H-X/Dh-Xvr5104He -X/Dh-Xvr5108H-4Kl-X-8P25
Dh-Xvr7108He-4K-X25
Dh-Xvr4216An-X/Dh-Xvr4232An-X/Dh-Xvr5216An-X/Dh-Xvr5232An-X/ Dh-Xvr5208An-4Kl-X/Dh-Xvr5216An-4Kl-X/Dh-Xvr5216A-X/Dh-Xvr5208An-4Kl-X-8P /Dh-Xvr5216An-4Kl-X-16P26
Dh-Xvr7208A-4Kl-X/Dh-Xvr7216A-4Kl-X/Dh-Xvr7208A-4K-X26
Dh-Xvr7416L-4Kl-X27
Dh-Xvr7816S-4Kl-X27
Dh-Xvr5432L-X27
Dh-Xvr5832S-X28
Rear Panel29
Dh-Xvr5108C-X/Dh-Xvr5104C-4Kl-X/Dh-Xvr5104C-X29
Dh-Xvr4104C-X/Dh-Xvr4108C-X29
Dh-Xvr7108E-4Kl-B-X30
Dh-Xvr4116Hs-X/Dh-Xvr5108Hs-X/Dh-Xvr5116Hs-X/Dh-Xvr5104Hs-4Kl-X/ Dh-Xvr5108Hs-4Kl-X/Dh-Xvr5104Hs-X/ Dh-Xvr4104Hs-X/Dh-Xvr4108Hs-X31
04He-X32
Dh-Xvr4216An-X/Dh-Xvr4232An-X/Dh-Xvr5216An-X/Dh-Xvr5232An-X/ Dh-Xvr5208An-4Kl-X/Dh-Xvr5216An-4Kl-X/Dh-Xvr5216A-X/Dh-Xvr7208A-4Kl-X/Dh- Xvr7216A-4Kl-X/Dh-Xvr7208A-4K-X33
Dh-Xvr5108H-4Kl-X-8P/Dh-Xvr5208An-4Kl-X-8P/Dh-Xvr5216An-4Kl-X-16P35
Dh-Xvr7416L-4Kl-X/Dh-Xvr5432L-X36
Dh-Xvr7816S-4Kl-X/Dh-Xvr5832S-X37
Remote Control Operations39
Mouse Operations41
Connecting Basics43
Typical Connection Diagram43
Connecting to Video and Audio Input and Output45
Video Input45
Video Output45
Audio Input46
Audio Output46
Connecting to Alarm Input and Output46
Introducing Alarm Port47
Alarm Input47
Alarm Output48
Alarm Output Relay Parameters48
Connecting to RS-485 Port49
Local Configurations50
Initial Settings50
Booting up50
Initializing the Device50
Resetting Password53
Setting up with the Startup Wizard60
Live View77
Live View Screen78
Live View Control Bar79
Navigation Bar82
Shortcut Menu83
Color Setting85
Live View Display87
Configuring Tour Settings92
Entering Main Menu95
Controlling PTZ Cameras98
Configuring PTZ Connection Settings98
Working with PTZ Control Panel100
Configuring PTZ Functions102
Calling PTZ Functions104
Calling OSD Menu106
Configuring Camera Settings107
Configuring Image Settings107
Configuring Encode Settings110
Configuring Snapshot Settings112
Configuring Overlay Settings113
Configuring Covered Area Settings114
Configuring Channel Type115
Upgrading Coaxial Camera116
Configuring Remote Devices117
Adding Remote Devices117
Managing Remote Devices129
Configuring Record Settings132
Enabling Record Control133
Configuring Recorded Video Storage Schedule134
Configuring Snapshot Settings134
Configuring Snapshot Trigger134
Configuring Snapshot Storage Schedule139
Backing up Snapshots to FTP139
Playing Back Video140
Enabling Record Control140
Instant Playback141
Main Interface of Video Playback141
Smart Search146
Marking and Playing Back Video147
Playing Back Snapshots149
Playing Back Splices149
Using the File List150
Alarm Events Settings152
Alarm Information152
Alarm Input Settings153
Alarm Output Settings160
Video Detection163
System Events172
Configuring IVS Function177
Configuring Intelligent Settings177
Enabling the Intelligent Settings for IP Camera192
Using Smart Search195
Configuring Face Detection198
Configuring Face Detection Settings198
Searching for Detected Faces201
Playing the Detected Faces203
Iot Function203
Configuring Sensor Settings203
Configuring Temperature and Humidity Camera211
Configuring Wireless Siren223
Configuring POS Settings224
Searching the Transaction Records224
Configuring POS Settings225
Configuring Backup Settings226
Finding USB Device226
Backing up Files227
Network Management228
Configuring Network Settings228
Configuring Network Testing Settings245
Configuring Account Settings250
Configuring User Account250
Configuring Group Account256
Configuring Onvif Users260
Audio Management261
Configuring Audio Files261
Configuring Playing Schedule for Audio Files263
Storage Management265
Configuring Basic Settings265
Configuring the Recording and Snapshot Schedule266
Configuring HDD Manager266
Configuring HDD Detecting Settings267
Configuring Record Estimate270
Configuring FTP Storage Settings272
Configuring System Settings274
Configuring General System Settings274
Configuring Security Settings276
Configuring System Maintenance Settings279
Exporting and Importing System Settings279
Restoring Default Settings281
Upgrading the Device282
Viewing Information285
Viewing Version Details285
Viewing Log Information286
Viewing Event Information288
Viewing Network Information289
Viewing HDD Information291
Viewing Channel Information292
Viewing Data Stream Information293
Viewing Poc Information294
Logout the Device295
Web Operations296
Connecting to Network296
Logging in the Web296
Resetting Password297
Introducing Web Main Menu301
Faq303
Glossary309
Appendix 2 HDD Capacity Calculation311
Appendix 3 Compatible Backup Devices313
Appendix 3.1 Compatible USB List313
Appendix 3.2 Compatible SD Card List314
Appendix 3.3 Compatible Portable HDD List314
Appendix 3.4 Compatible USB DVD List314
Appendix 3.5 Compatible SATA DVD List314
Appendix 3.6 Compatible SATA HDD List315
Appendix 4 Compatible CD/DVD Burner List320
Appendix 5 Compatible Displayer List321
Appendix 6 Compatible Switcher322
Appendix 7 Earthing323
Appendix 7.1 What Is the Surge323
Appendix 7.2 the Earthing Modes324
Appendix 7.3 Thunder Proof Ground Method in the Monitor System325
Appendix 7.4 the Shortcut Way to Check the Electric System by Digital Multimeter326
Appendix 8 RJ45-RS-232 Connection Cable Definition329
