Figure 5-58
Figure 5-59
Please refer to the following sheet for detailed information.
You need to check the box to enable motion detection function.
Please select a channel from the dropdown list.
Motion detection function becomes activated in the specified
periods. See Figure 5-55.
There are six periods in one day. Please draw a circle to enable
corresponding period.
Click OK button, system goes back to motion detection interface,
please click save button to exit.
System only memorizes one event during the anti-dither period.
The value ranges from 5s to 600s.
There are six levels. The sixth level has the highest sensitivity.
If you select motion detection type, you can click this button to set
motion detection zone. The interface is shown as in Figure 5-56.
Here you can set motion detection zone. There are four zones for
you to set. Please select a zone first and then left drag the mouse
to select a zone. The corresponding color zone displays different
detection zone. You can click Fn button to switch between the arm
mode and disarm mode. In arm mode, you can click the direction
buttons to move the green rectangle to set the motion detection
zone. After you completed the setup, please click ENTER button to
exit current setup. Do remember click save button to save current
setup. If you click ESC button to exit the region setup interface
system will not save your zone setup.
System auto activates motion detection channel(s) to record once
an alarm occurs. Please note you need to set motion detect record
period and go to Storage-> Schedule to set current channel as
schedule record.
