Figure 4-21
Manual Add: Click Manual Add button, you can set the corresponding network camera
information and then select the channel you want to add. See Figure 4-22.
Manufacturer: Please select from the dropdown list.
Note
Different series products may support different manufactures, please refer to the actual
product.
IP address: Input remote device IP address.
RTSP port: Input RTSP port of the remote device. The default setup is 554.
Note
Skip this item if the manufacture is Private or General.
HTTP port: Input HTTP port of the remote device. The default setup is 80.
Note
Skip this item if the manufacture is ONVIF or General.
TCP port: Input TCP port of the remote device. The default setup is 37777.
User name/password: The user name and password to login the remote device.
Channel No.: Input channel amount or click the Connect button to get the channel
amount of the remote device.
Note
