Dahua NVR41 series

User's Manual
6
Figure 2-3 Front panel
Table 2-3
Icon
Name
Function
HDD
HDD status indicator
light
The blue light is on when the
HDD is malfunction.
NET
Network status indicator light
The blue light is on when the
network connection is abnormal.
POWER
Power status indicator light
The blue light is on when the
power connection is OK.
USB2.0 port
Connect to peripheral USB 2.0
storage device, mouse, burner
and etc.
2.1.4 NVR41-8P Series
The front panel is shown as below. See Figure 2-4.
