User's Manual
11
series front panel is shown as in Figure 2-9.
Figure 2-9
The NVR58-4KS2/58-16P-4KS2/48-4KS2/48-16P-4KS2/58-16P-4KS2E series front panel is
shown as in Figure 2-10
Figure 2-10
Table 2-8
Icon
Name
Function
STATUS
Status indicator light
The blue light is on when the
device is malfunction.
HDD
HDD status indicator light
The blue light is on when the
HDD is malfunction.
NET
Network status indicator light
The blue light is on when the
network connection is
abnormal.
POWER
Power status indicator light
The blue light is on when the
power connection is OK.
USB2.0 port
Connect to peripheral USB 2.0
storage device, mouse, burner
and etc.
2.1.9 NVR44/44-8P/44-16P Series
The front panel is shown as in Figure 2-11.
Figure 2-11
Table 2-9
Icon
Name
Function
Power button
Power button, press this button for three seconds
to boot up or shut down NVR.
