Dahua NVR41 series

User's Manual
19
Figure 2-16
2.1.15 NVR1104HS-W/NVR1108HS-W Series
The NVR1104HS-W/NVR1108HS-W series front panel is shown as below. See Figure 2-17.
Figure 2-17
Table 2-13
Icon
Name
Function
HDD
HDD status indicator light
The blue light is on when the HDD is
malfunction.
NET
Network status indicator light
The blue light is on when the network
connection is abnormal.
POWER
Power status indicator light
The blue light is on when the power
connection is OK.
USB2.0 port
Connect to peripheral USB 2.0
storage device, mouse and etc.
