User's Manual
316
Figure 4-215
4.12.7 PPPoE
PPPoE is another way for the Device to access the network. You can establish network
connection by configuring PPPoE settings to give the Device a dynamic IP address in the
WAN. To use this function, firstly you need to obtain the user name and password from the
Internet Service Provider.
Step 1 Select
Main Menu
>
NETWORK
>
PPPoE
.
The
PPPoE
interface is displayed. See Figure 4-216.
Figure 4-216
Step 2 Enable the PPPoE function.
Step 3 In the
User Name
box and
Password
box, enter the user name and password
accordingly provided by the Internet Service Provider.
Step 4 Click
Apply
to complete the settings.
The system pops up a message to indicate the successfully saved. The IP address
appears on the PPPoE interface. You can use this IP address to access the Device.
