User's Manual
349
4.15.2.2 802.1x
The device needs to pass 802.1x certification to enter the LAN.
Step 1 Select
Main Menu
>
SECURITY
>
Systm Service
>
802.1x
.
The
802.1x
interface is displayed. See Figure 4-251
Figure 4-251
Step 2 Select the Ethernet card you want to certify.
Step 3 Select
Enable
and configure parameters. See Table 4-82.
Table 4-82 802.1x parameters
● PEAP: protected EAP protocol.
● TLS: Transport Layer Security. Provide privacy and data
integrity between two communications application programs.
Enable it and click
Browse
to import CA certificate from flash
drive. For details about importing and creating a certificate, see
"4.15.4 CA Certificate".
The username shall be authorized at server.
Password of the corresponding username.
Step 4 Click
Apply
to complete the settings.
