2.2.20 NVR11 HC-S3 Series
The NVR1104HC-S3/NVR1108HC-S3 series rear panel is shown as below. See Figure 2-73.
Figure 2-73
The NVR1104HC-P-S3 rear panel is shown as below. See Figure 2-74.
Figure 2-74
The NVR1108HS-8P-S3 rear panel is shown as below. See Figure 2-75.
Figure 2-75
Table 2-32
Icon
Name
Function
/
Power input
socket.
Power socket.
● NVR1104HC-S3/NVR1108HC-S3: Input
DC12V/2A.
● NVR1104HC-P-S3: Input DC48V/DC53,
1.25A/1.13A.
● NVR1108HS-8P-S3: Input DC48V/DC53V,
2A/1.8A.
Network port
10M/100Mbps self-adaptive Ethernet port.
Connect to the network cable.
USB2.0 port
USB2.0 port. Connect to mouse, USB storage
device, and etc.
HDMI
High Definition
Media Interface
High definition audio and video signal output port.
It transmits uncompressed high definition video
and multiple-channel data to the HDMI port of the
display device. HDMI version is 1.4.
