Dahua NVR41 series User Manual

User's Manual
9
Icon
Name
Function
Slow play/8
Multiple slow play speeds or normal playback.
In text mode, input number 8 (English character
T/U/V).
Assistant
Fn
One-window monitor mode, click this button to
display assistant function: PTZ control and image
color.
Backspace function: in numeral control or text
control, press it for 1.5seconds to delete the
previous character before the cursor.
In motion detection setup, working with Fn and
direction keys to realize setup.
In text mode, click it to switch between numeral,
English character(small/capitalized) and etc.
Fast play/7
Various fast speeds and normal playback.
In text mode, input number 7 (English character
P/Q/R/S).
Play previous/0
In playback mode, playback the previous video.
In text mode, input number 0.
Reverse/Pause/
6
In normal playback or pause mode, click this
button to reverse playback.
In reverse playback, click this button to pause
playback.
In text mode, input number 6 (English character
M/N/O).
Play Next/9
In playback mode, playback the next video.
In menu setup, go to down ward of the drop-down
list.
In text mode, input number 9 (English character
W/X/Y/Z).
Play/Pause /5
In normal playback click this button to pause
playback.
In pause mode, click this button to resume
playback.
In text mode, input number 5(English character
J/K/L).
USB port
To connect USB storage device, USB mouse.
Network
abnormal
indicator light
Net
Network error occurs or there is no network
connection, the light becomes red to alert you.
HDD abnormal
indicator light
HDD
HDD error occurs or HDD capacity is below
specified threshold value, the light becomes red
to alert you.
Record light
1-16
System is recording or not. It becomes on when
system is recording.
IR Receiver
IR
It is to receive the signal from the remote control.
